SA8x6x
Budget-friendly price Request a quote
Multiparameter probe
- Manufacturer: B&C Electronics
- Category: Water quality, SENSORS, Multiparameter Probes
Equipped with 6 sensors: Level, conductivity, temperature, pH, redox, dissolved oxygen (turbidity option). With or without recorder, RS485-ModBus signal, level of 20 or 350 meters.
Properties
| SA 8060.101 | Recorder, level 20 m., power supply battery |
| SA 8060.104 | Recorder, level 350 m. , alim. battery |
| SA 8065.101 | Communication, level 20 m., external power supply. |
| SA 8065.104 | Communication, level 350 m., outside power supply. |
| SA 8265.106 | Communication, level 20 m., external supply, atmospheric comp. |
