A/959CP Absolute Fieldbus Encoder
- Manufacturer: ELCIS Encoder
- Category: Encoder, Absolute Encoder, Absolute Encoder Fieldbus, SENSORS
The A/959CP is a compact and robust absolute encoder with a hollow shaft and integrated flexible coupling, featuring a PROFIBUS-DP interface. It is servo-mounted using front-mounted clips or screws and offers high resolution at an excellent price/performance ratio.
The A/959CP is a single-turn or multi-turn absolute encoder with a PROFIBUS-DP Class 2 interface and RS485 line driver, with a transmission speed of up to 12 MBaud. It allows selection of 4096, 8192, 16384, 32768, or 65536 steps per revolution and 1, 4096, or 16384 revolutions, with a maximum of 30 bits in binary code. The address is programmed using selectors on the terminal box, and two LEDs indicate the status.
Constructed with a Ø59 mm aluminum housing and a hollow F7 stainless steel shaft (standard Ø15 mm; Ø8, Ø10, Ø12, or others available upon request), its integrated elastic coupling allows for a maximum compensation of ±0.1 mm axially, ±0.2 mm radially, and ±1° angularly, and supports radial and axial loads of 40 and 110 N. It features IP64 protection on the shaft side (IP66 in the sealed version), withstands 30 G shocks and 10 G vibrations, and operates from -40 to +85 °C. Available in guemisa.es.
- Interface PROFIBUS-DP Class 2 with RS485 line driver up to 12 MBaud.
- Hollow shaft with built-in elastic coupling: compensates ±0.1 mm axial, ±0.2 mm radial and ±1° angular.
- Resolution of up to 16 bit per turn and 30 bit in 16384 turns.
- Programmable steering with selectors and 2 LED of state.
Technical Frequently Asked Questions
What compensation does the elastic coupling of the A/959CP allow?
The built-in elastic coupling allows a maximum compensation of ±0.1 mm axial, ±0.2 mm radial and ±1° angular.
What hollow shaft diameters are available?
The standard diameter is Ø15 mm, with F7 tolerance. There are also options of Ø12, Ø10 and Ø8 mm and other diameters available upon request.
What parameters are programmable on the PROFIBUS-DP interface?
Direction of rotation (complement), resolution per revolution, total resolution, preset value, speed output and software limit switches.
Properties
| Feature | Specification |
|---|---|
| Housing | Aluminum Ø59 mm (custom options) |
| Weight | 550 g single turn · 600 g multiturn |
| Shaft (stainless steel) | F7 Hole: Standard Ø15 mm; Ø8, Ø10, Ø12 or others upon request |
| Elastic coupling | Max. compensation: axial ±0.1 mm · radial ±0.2 mm · angular ±1° |
| max radial/axial load. | 40 / 110 N |
| Shaft/outlet protection | IP64 shaft (IP66 sealed) · IP65 outlet |
| max. continuous RPM | 6000 standard · 3000 sealed (intermittent: +30 %) |
| Impact/vibration resistance | 30G (11ms) 10G (10–1000Hz) |
| Power supply / max. consumption. | 10–30 V DC · 2.5 W |
| LSB pitch frequency | 800 kHz |
| Operating/storage temperature | -40 … +85 °C / -40 … +85 °C |
| Exit code | Binary |
| Division accuracy | ±½ LSB (<13 bit) · ±2 LSB (13–16 bit) |
| Max resolution. | 16 bits/turn · 30 bits in 16384 turns |
| Interface | PROFIBUS-DP Class 2 (DP) · RS485 · max. 12 MBaud |
