SZ3273.4 CONDUCTIVITY SENSOR

Graphite sensor with built-in NTC10K, 3m cable, K=1 cm⁻¹Range from 2MicroSiemens to 2,000 milliSiemens,

Manufacturer: B&C Electronics
Category: Water quality, SENSORS, Conductivity Sensors

B&C Electronics' SZ3273.4 graphite electrical conductivity sensor with 10K NTC temperature compensation is a conductivity transmitter designed to measure electrical conductivity in a wide variety of industrial processes and with high accuracy.

It is capable of operating up to 80 °C and 10 bar pressure, with a measurement range of 2µS to 2,000 mS.

It is equipped with concentric graphite electrodes on a flat surface and has a cell constant K=1 cm⁻¹. Its plastic body measures 110 mm in length and 12 mm in diameter and includes a 3m cable.

By using graphite electrodes, polarization problems are minimized and measurement stability is ensured.

It is specially designed for applications such as: Monitoring of fertigation systems, hydroponic crops, greenhouses, quality control in industrial processes, analysis in water and soil laboratories.

Compatible with drivers: C3645.

For in-line installation with adapters: SZ7101, SZ7105 or SZ7108

For submerged installation with SZ8X adapters, except for the SZ862 and SZ882.

Properties

Measuring range:	K=1 cm^-1 ± 0.15 (2 µS to 2,000 mS)
Body material:	Epoxy
Electrodes:	2 graphite electrodes in concentric configuration
Size:	110mm and diameter 12
Maximum working temperature:	80ºC
Temperature sensor:	NTC 10K
Electrical connection:	5-wire coaxial cable, 3m Model: SZ927.1
Maximum working pressure	10Bar
