DPF-AN2TH
Analog-digital temperature and humidity controller sensor with LED signaling, relay alarm, for indoor use.
- Manufacturer: DPF Sensors
- Category: SENSORS, Humidity Sensors, Temperature sensors, Temperature sensors for air conditioning
Analog-digital temperature and humidity controller sensor with LED signaling, relay alarm, for indoor use.
Output signal 0-10 Vdc + 8 amp NA relay
Ranges: Temperature: 0…+50ºC / humidity: 0….100%
Power supply: 110-230 Vac
Properties
