Single-turn Absolute Encoder A/368
- Category: Encoder, Absolute Encoder, Single-turn Absolute Encoder, SENSORS
The A/368 Single-Turn Absolute Encoder addresses the need for precise positioning in single-turn applications without data loss during power cycles. Designed for general industrial use, it combines mechanical strength and precise circuit design to maintain system stability under varying load conditions.
It offers up to 11-bit resolution with multiple power supply options including 5V, 15V, and 8V to 30V ranges. The parallel interface allows direct integration into PLCs, while the SSI and analog outputs provide flexibility for line driver applications in complex control architectures.
Constructed with an anodized aluminum base and stainless steel shaft, it withstands vibration and impact up to 50G. This robust design ensures long-term reliability in harsh environments, guaranteeing continuous operation under extreme temperature and humidity conditions. Technical consultation available at [website/contact information missing]. guemisa.es.
- Resolution up to 11 bits for precise positioning in single-turn systems.
- Flexible power supply compatible with 5V, 15V and ranges of 8 to 30 volts.
- Robust construction in anodized aluminum with stainless steel shaft.
- Standard parallel or serial SSI interface for direct integration into PLCs.
Technical Frequently Asked Questions
What alignment precautions does the A/368 axle require?
The stainless steel shaft supports a maximum radial and axial load of 2 kg. It is crucial to respect the starting torque of 18 / 30 / 8 gcm to avoid damage to the sealed ball bearings, ensuring a service life of 1.5×10^9 revolutions under normal operating conditions.
What connectors and output options are available for the A/368?
Multiple connection options are offered, such as PT02A16-26P IP65 or MS310A18-1P IP65. Outputs include standard parallel, SSI, analog current (mA) or voltage (V), and the option for resolutions from 1 to 12 bits, adapting to different electronic interface needs.
What are the operating temperature limits of the A/368?
Operation is guaranteed between 0 and +70°C, with a wide storage range of -30 to +85°C. The device can withstand burn-in at +75°C for 72 hours, allowing its use in demanding thermal environments without compromising the integrity of the optical or electronic circuitry.
How is the analog signal integrated with external control systems?
The analog output converts the angular position into current (1–20 mA) or voltage (0–10 V), providing a signal proportional to the value. This allows direct connection to PLC or controller inputs that require line driver signals, facilitating position reading without the need for additional decoders.
Properties
| Feature | Specification |
|---|---|
| Vcc Power Supply | 18–28 V, 5 V ±5%, 15 V ±5%, 8–24 V, 10–30 V |
| Maximum Frequency | 50 kHz |
| Operating Temperature | 0 – +70 °C |
| Exit Stages | Parallel, SSI, Analog Current/Voltage |
| Base | Anodized aluminum |
| Weight | 320 g |
| Axis | Ø 5 mm / 8 / 9.52 / 10 / 12 mm Stainless Steel |
| Max Radial/Axial Load | 2 Kg |
| IP Output Side | IP65 |
| Maximum RPM | 6.000 / 3.000 / 8.000 |
| Starting Torque | 18 / 30 / 8 gcm |
| Bearing Life | 1.5×10^9 revolutions |
| Resolution | 2 to 11 bits (4 to 2048 positions) |
| Impact Resistance | 50 G x 11 ms |
| Vibration Resistance | 12 G (10 – 2000 Hz) |
