Special Incremental Encoder I/90G
- Manufacturer: ELCIS Encoder
- Category: Encoder, Incremental Encoder, Special Incremental Encoder, SENSORS
El ELCIS 90G (I/90G) es un encoder incremental íntegramente de acero inoxidable, con carcasa Ø90 mm y de 1 a 90000 impulsos por vuelta. Es apto para condiciones ambientales particularmente severas y/o corrosivas, y adecuado para las industrias química, alimentaria y marina. El peso es de 2000 g y la longitud total con el eje es de 116 mm. El eje macizo es de Ø12 h7 mm, con chavetero de 4 mm y 30 mm de saliente, y admite una carga radial/axial máx. de 15 kg. Frecuencia máx. de 100 kHz (300 kHz opcional, opción W). El grado IP en el lado del eje es IP65 (estándar), IP66 con rodamiento sellado (opción Z) o IP53 con rodamiento de bajo par (opción B).
The base, cover, and shaft are made of stainless steel; the weight is 2000 g and the body measures Ø90 mm (116 mm total length with the shaft). The solid shaft is Ø12 h7 mm, with a 4 mm keyway and 30 mm projection, and supports a maximum radial/axial load of 15 kg.
Ofrece de 1 a 90000 impulsos por vuelta y una frecuencia máx. de 100 kHz (300 kHz opcional, opción W). El grado IP en el lado del eje es IP65 (estándar), IP66 con rodamiento sellado (opción Z) o IP53 con rodamiento de bajo par (opción B).
- Stainless steel: base, lid and shaft made of stainless steel, weighing 2000 g.
- 15 kg load: max. radial/axial load on the Ø12 h7 mm shaft.
- Up to 90,000 imp/v: from 1 to 90000 pulses per revolution; max. frequency 100 kHz (300 kHz optional, option W).
- IP65 / IP66 / IP53: IP65 standard on the shaft side, IP66 with option Z (sealed bearing) and IP53 with option B (low torque bearing).
Technical Frequently Asked Questions
What material is the I/90G encoder made of?
The base, lid, and shaft are made of stainless steel, with a weight of 2000 g. ELCIS describes it as being made entirely of stainless steel and suitable for the chemical, food, and marine industries.
What is the axle like and what load can it support?
The solid shaft is Ø12 h7 mm, with a 4 mm keyway, and supports a maximum radial/axial load of 15 kg.
What IP protection rating does it have?
On the shaft side, IP65 (standard), IP66 with sealed bearing (option Z) or IP53 with low torque bearing (option B). On the output side, it depends on the connection.
Properties
| Feature | Specification |
|---|---|
| Mechanics | |
| Housing | Made entirely of stainless steel (base and lid) |
| Weight | 2000 g |
| Axis | Ø 12 mm in stainless steel with 4 mm keyway (customizable upon request) |
| max. axial/radial load. | 15 kg |
| Electric | |
| Exit-side protection | According to connection (see "Possible Connections") (IP ratings according to IEC EN 60529, EN 60529, IEC 529) |
| Feeding | 5÷30 Vcc according to code |
| Impulses per lap | 1 to 90000 imp/v |
| Maximum frequency | 100 kHz (300 kHz with W option) |
| Maximum consumption | 120 mA (standard) / 180 mA (line driver) (customizable upon request) |
| Protection and environment | |
| axle-side protection | IP65 standard / IP66 sealed (Z) / IP53 low torque (B) (IP ratings according to IEC EN 60529, EN 60529, IEC 529) |
| Maximum continuous speed | 6000 rpm (standard) / 3000 rpm (sealed Z) / 8000 rpm (low torque B); intermittent +30 % (maximum intermittent speed: +30 % of continuous) |
| Impact resistance | 50 G (11 ms) |
| Vibration resistance | 12 G (10 to 2000 Hz) |
| Operating temperature | -20 °C +85 °C (standard) (customizable upon request) |
| Storage temperature | -30 °C at +85 °C |
