Incremental Encoder for Motors I/59ZP
- Manufacturer: ELCIS Encoder
- Category: Encoder, Incremental Encoder, Incremental Encoder for Motors, SENSORS
El ELCIS 59ZP (I/59ZP) es un encoder incremental de Ø59 mm, con perno antirrotación Ø5 mm, eje hueco pasante y de 1 a 3600 impulsos por vuelta. Es apto para su uso en motores.
It has an anodized aluminum base and a Valox 420 lid, weighs 300g, and accepts stainless steel through shafts of Ø6, Ø8, Ø10, Ø12 and Ø15 mm (Øn on request). The anti-rotation bolt is Ø5 mm.
Genera de 1 a 3600 impulsos por vuelta con una frecuencia máx. de 100 kHz (300 kHz opcional) y se ofrece con electrónicas NPN, PNP, push-pull, line driver, TTL y sinusoidal 1 Vpp, con salida radial por cable o conector. La fuente de luz es un LED con vida ≥ 100000 h.
- Anti-rotation bolt: of Ø5 mm, with its dimensions on the dimensional drawing.
- Protection: IP64 on the shaft side (IP65 sealed with option Z, IP53 under torque with option B); on the output side, depending on the connection.
- Speed: 6000 rpm continuous in standard version, 3000 rpm sealed (option Z) and 8000 rpm under torque (option B).
- Bearings: life of 1.5 × 10⁹ revolutions and max. axial/radial load of 6 kg.
Technical Frequently Asked Questions
What through shaft diameters does the I/59ZP model support?
Ø6, Ø8, Ø10, Ø12 and Ø15 mm; other diameters (Ø n), on request.
What IP protection rating does the I/59ZP have?
On the shaft side, IP64 in the standard version, IP65 in the sealed version (option Z), and IP53 in the low-torque version (option B). On the output side, it depends on the connection: IP65 with CV cable and IP67 with CH, CH5, and CH6 connectors.
What outputs does the I/59ZP encoder offer?
NPN, NPN open collector, PNP, PNP open collector, push-pull, TTL 7404, 26LS31 driver, 88C30 driver and sinusoidal 1 Vpp.
Properties
| Feature | Specification |
|---|---|
| Mechanics | |
| Weight | 300 g |
| Axis | Eje pasante Ø 6÷15 mm en acero inoxidable (personalizable bajo pedido) |
| max. axial/radial load. | 6 kg |
| Bearing life | 1.5 × 10⁹ revolutions |
| Electric | |
| Exit-side protection | According to connection (protección lado salida y lado eje: IP según CEI EN 60529, EN 60529, IEC 529) |
| Feeding | 5÷30 Vcc (according to code) |
| Max. consumption. | 120 mA (standard) / 180 mA (line driver) (customizable upon request) |
| Impulses per lap | 1 to 3600 |
| Max frequency. | 100 kHz (300 kHz optional) |
| Protection and environment | |
| axle-side protection | IP64 estándar / IP65 sellado (opción Z) / IP53 bajo par (opción B) (protección lado salida y lado eje: IP según CEI EN 60529, EN 60529, IEC 529) |
| max. continuous RPM | 6000 rpm (estándar) / 3000 rpm (sellado, opción Z) / 8000 rpm (bajo par, opción B) (intermitentes: +30 %) |
| Impact resistance | 50 G × 11 ms |
| Vibration resistance | 12 G (10 ÷ 2000 Hz) |
| Working temperature | 0 ÷ +70 °C (customizable upon request) |
| Storage temperature | -30 ÷ +85 °C |
| Reference | Configuration |
|---|---|
| I/59ZP11-1024-5-BZ-N-CH-RI59ZP1110245BZNCHR | 1024 impulsos/vuelta · 5 V ±5 % · bidireccional + impulso cero · Driver 26LS31 · Conector 12 c. antihorario IP67 · salida radial |
| I/59ZP12-1024-5-BZ-B-CV-RI59ZP1210245BZBCVR | eje Ø 12 mm · 1024 impulsos/vuelta · 5 V ±5 % · bidireccional + impulso cero · Push-pull pro · Cable radial IP65 · salida radial |
| I/59ZP15-1024-5-BZ-N-CH-RI59ZP1510245BZNCHR | eje Ø 15 mm · 1024 impulsos/vuelta · 5 V ±5 % · bidireccional + impulso cero · Driver 26LS31 · Conector 12 c. antihorario IP67 · salida radial |
| I/59ZP15-25-1828-B-B-VL-R-01I59ZP15251828BBVLR01 | eje Ø 15 mm · 25 impulsos/vuelta · 18 ÷ 28 V · bidireccional · Push-pull pro · Cable con conector 10 contactos estándar · salida radial |
| I/59ZP15-500-5-BZ-N-CH-RI59ZP155005BZNCHR | eje Ø 15 mm · 500 impulsos/vuelta · 5 V ±5 % · bidireccional + impulso cero · Driver 26LS31 · Conector 12 c. antihorario IP67 · salida radial |
| I/X59ZP15-25-1828-B-B-VL-R-01IX59ZP15251828BBVLR01 | opciones personalizadas · eje Ø 15 mm · 25 impulsos/vuelta · 18 ÷ 28 V · bidireccional · Push-pull pro · Cable con conector 10 contactos estándar · salida radial |
