Linear LVDT with Integrated Electronics SM40 Series
- Manufacturer: Schreiber Messtechnik
- Category: Displacement, Amplified LVDTs, SENSORS, Sensores LVDT
He Linear LVDT The Schreiber SM40 series is the flagship displacement measurement device with integrated electronics for long-travel industrial applications. Designed in a robust stainless steel housing... 25 mm in diameter, This inductive transducer eliminates the need for external signal conditioners by processing the signal internally and delivering standard mA or Vcc outputs. This compact architecture ensures a signal stability and EMI immunity superior, allowing a 1:1 compatibility / drop-in replacement in heavy machinery, hydraulic presses and automation systems where long-term reliability is non-negotiable.
This displacement transducer It achieves measurement ranges of up to 360 mm, maintaining exceptional linearity of 0.5% and a dynamic response of 800 Hz. Thanks to its IP67/IP68 protection rating and multiple mechanical options (spring-loaded probe, ball joints, or fiberglass protective sheath), the SM40 is suitable for even the harshest and most contaminated environments. It is the ultimate technical solution for engineers seeking a robust position sensor with infinite resolution and easy direct integration into PLCs via an M12 connector or cable output. Request the CAD drawing for the version with FGH ball joints here.
SM433.240.1.X33
SM433.360.1.X33
SM413.150.1.X33
SM413.70.1.X33
Properties
| Engineering Parameter | Technical Specification SM40 |
|---|---|
| Applied Technology | Inductive LVDT with Integrated Amplifier Electronics |
| Stroke Ranges (mm) | 20, 40, 70, 80, 100, 150, 170, 200, 240, 360 |
| Current Outputs (.4×1-4) | 0-20mA | 4-20 mA (Configurable) |
| Voltage Outputs (.4×5-8) | ± 10 VDC | 0-10 VDC (Short circuit protection) |
| Casing Diameter | 25 mm (AISI 303 Stainless Steel) |
| Relative Linearity | ± 0.5% (Standard) | ± 0.25% (Optional) |
| Degree of Protection | IP67 (Standard) | IP68 (Optional) |
| Frequency Limit | 800 Hz (High dynamic response) |
| Operating Thermal Range | -40 °C to +85 °C |
| Zero Stability | < 0.01% / °C (Design compensation) |
| Vibration/Shock Resistance | 20 g rms | 250 g SRS (Heavy Industrial Use) |
| Distance between holes on support | 30.0 mm (SM906.400 / 401 Clamps) |
| Direct Power Supply Vcc | 20 .. 32 VDC (Reverse polarity protection) |
| Maximum Consumption | 60 mA (Full load) |
| Types of Physical Output | M12 connector (4 poles) | PG9 stainless steel cable |
