Incremental Encoder Kit and Low Cost I/90ZA
- Manufacturer: ELCIS Encoder
- Category: Encoder, Incremental Encoder, Incremental Encoder Kit Low Cost, SENSORS
In demanding industrial environments, the need for a robust incremental encoder for dividing tables or servo assembly applications is critical. The I/90ZA model offers an architecture designed to withstand high mechanical loads and constant vibrations without compromising the accuracy of the position data transmitted to the controller.
The technical solution integrates a stainless steel shaft between 16 and 30 mm, supporting up to 6 kg of radial load. With a configurable resolution from 1 to 36,000 pulses per revolution and a maximum frequency of 100 kHz, it guarantees the precise capture of rapid movements in heavy machinery.
The construction uses anodized aluminum for the base and lid, ensuring durability with standard IP65 protection. Resistant to 50G impacts and 12G vibrations, it operates between 0 and 70°C under normal conditions, making it a reliable component available in guemisa.es.
- Anodized aluminum structure with standard IP65 protection.
- Certified bearing life at 1.5 x 10^9 revolutions.
- Starting torque greater than 80 gcm for high inertia.
- Maximum operating frequency up to 100 kHz with 500 option.
Technical Frequently Asked Questions
How does the I/90ZA differ from its sibling model, the I/90Z?
The I/90ZA weighs 750 grams compared to the I/90Z's 600 grams, offering a radial and axial load capacity of 6 kg versus the Z model's 10 kg. Although the I/90Z is lighter, the I/90ZA is specifically optimized for servo mounting applications with tight internal tangential coupling.
What alignment precautions does the I/90ZA shaft require?
The shaft supports a maximum radial and axial load of 6 kg. It is recommended to ensure angular compensation of ±1° during assembly to prevent premature wear of the bearings, whose service life is certified at 1.5 x 10^9 revolutions under standard continuous operating conditions.
What connectors and output options are available for the I/90ZA?
The model supports multiple connection configurations such as a RAD terminal box or a 7-pin VM connector. Outputs include NPN, PNP, Open Collector, and Push-Pull PRO, allowing flexible integration into standard or industrial control systems without the need for complex external adapters.
Properties
| Feature | Specification |
|---|---|
| Sensor Type | Incremental |
| Main Application | Servo-Mount / Dividing Tables |
| Power Supply | 5V DC ±5% (Optional 8÷24V) |
| Axis | Ø16÷30 mm Stainless Steel |
| Maximum Radial/Axial Load | 6 kg |
| Maximum Continuous RPM | 500 RPM |
| Starting Torque | > 80 gcm |
| Bearing Life | 1.5 x 10^9 Revolutions |
| Impact Resistance | 50 G x 11ms |
| Vibration Resistance | 12 G (10 ÷ 2000 Hz) |
| Operating Temperature | 0 ÷ 70 °C |
| Pulses/Revolution (PPR) | 1 ÷ 36000 |
| Maximum Frequency | 100 kHz (Option 500) |
| IP Protection Output | IP65 Standard |
| Total Weight | 750 grams |
