Incremental Encoder for Racks I/45C
- Manufacturer: ELCIS Encoder
- Category: Encoder, Incremental Encoder, Incremental Encoder for Rack and Pinion, SENSORS
Encoder with all-metal pinion, for use with CR80 linear transducer in linear dimension measurement, with resolution from 0.001 to 1 mm and integrated pinion preload system.
The I/45C offers 1 to 10,000 pulses per revolution, a maximum frequency of 40 kHz (100 kHz optional), and features NPN, PNP, push-pull, TTL 7404 electronics, 26LS31 and 88C30 drivers, and a 1 Vpp sine wave output (max. 1024 ppr). It operates on a 5 to 30 V supply depending on the version.
Anodized aluminum base and cover, and stainless steel pinion with 13 or 16 teeth. LED light source with a lifespan of ≥ 100,000 hours. Supports 0.5 kg radial/axial load, operates from 0 to +70 °C with IP64 protection on the shaft side (IP66 sealed), and connects via a 1 m cable, a 9-pin sub-D connector, or a cable end connector. Available in guemisa.es.
- Compatible with CR80 linear transducer; LED light source with life ≥ 100,000 h.
- Resolution of 0.001 to 1 mm and of 1 to 10000 pulses per lap, with a frequency of up to 40 kHz (100 kHz optional).
- Stainless steel pinion 13 either 16 teeth and high MTTFd according to EN ISO 13849-1.
- Nutrition 5 to 30 V depending on the version and electronics: NPN, PNP, push-pull, TTL 7404, 26LS31 and 88C30 drivers and sinusoidal 1 Vpp.
Technical Frequently Asked Questions
What pinions does the I/45C accept?
13-tooth pinion (B) or 16-tooth pinion (C).
What connections does it offer?
1 m cable (CV), 9-pin sub-D connector (CD) or cable end connector.
What is the limit of the sinusoidal output?
Up to 1024 ppr with Y electronics (1 Vpp sinusoidal).
Properties
| Feature | Specification |
|---|---|
| Mechanics | |
| Weight | 280 g |
| Pinion | Stainless steel, with integrated preload system (see "Possible Sprockets") |
| max radial/axial load. | 0,5 kg |
| Electric | |
| Linear resolution | 0.001 to 1 mm |
| Exit-side protection | Según conexión: IP64 a IP65 (ver ficha técnica) |
| Feeding | 5–30 V according to version (see technical specifications) |
| Max. consumption. | 120 mA Standard · 180 mA line driver (customizable upon request) |
| Impulses per lap | 1 to 10000 |
| Max frequency. | 40 kHz (100 kHz optional) |
| Protection and environment | |
| axle-side protection | IP64 standard · IP66 sealed (Z) (without low torque option) |
| max. continuous RPM | 4000 standard · 3000 sealed (intermittent: +30 %; no low torque option) |
| Impact resistance | 50 G × 11 ms |
| Vibration resistance | 12 G (10–2000 Hz) |
| Operating temperature | 0 … +70 °C (customizable upon request) |
| Storage Temp. | -30 … +85 °C |
