DPFS-xxx
Compact ultrasound stations, RS485 ModBus communication
- Manufacturer: DPF Sensors
- Category: Complete weather stations, Meteorology – Climatology, SENSORS
Intelligent ultrasonic weather stations integrate wind speed, wind direction, temperature, humidity, noise, PM2.5 and PM10, atmospheric pressure, solar radiation, and rainfall.
RS485 output signal, 24 Vdc power supply.
