DPF-CO2-ANCO2L
Indoor CO2 sensor, range up to 4000 ppm, analog output and relay alarm
- Manufacturer: DPF Sensors
- Category: SENSORS, Gas Sensors
Indoor CO2 sensor, range up to 4000 ppm, analog output and relay alarm
Output signal 0-10 Vdc / open contact alarm
Power supply 110-230 Vac
NDIR sensor
Properties
