F0eS torque transducer
- Category: Torque torque, SENSORS
The series F0eS It represents the technological pinnacle in the measurement of rotary torque. CENSORED. Designed specifically for ultra-high dynamic test benches, this transducer integrates a digital optical measurement system that overcomes the limitations of conventional sensors, offering exceptional signal resolution and unprecedented thermal stability.
Precision in E-Mobility
Thanks to its optimized titanium/steel rotor, the F0eS offers the lowest moment of inertia in its class and extreme torsional rigidity. These characteristics make it the benchmark for the development of high-performance electric motors (E-Mobility) and racing transmissions, where transient peak capture and frequency response are critical.
The system guarantees interference-free, digital 100% data transmission. Available in High Speed (HS) versions up to 30,000 rpm, the F0eS integrates seamlessly into modern automation environments thanks to its multiple simultaneous outputs: high-speed RS422 frequency, precision analog, and Fieldbus (CAN).
Properties
Technical Specifications
| Nominal Pair (Mdn) | 50 … 1,000 Nm |
| Accuracy Class | ≤ ± 0.05 % (Optional 0.03%) |
| Maximum speed | Up to 30,000 rpm (HS) |
| Allowable Overload | 500 % from Mdn |
| Torsional Stiffness | 23 … 356 kNm/rad |
| Feeding | 23 … 25 V DC |
| Output Frequency | RS422 (60 kHz) |
| Analog Output | ± 10 V / 4…20 mA |
| Country Bus | CAN Bus |
| IP protection | IP54 |
