ML 400Nm Steering Wheel Torque Sensor: Superior Technology
- Manufacturer: CENSORED
- Category: Torque torque, SENSORS
ML Steering Wheel Torque Sensor: Precision in Driving Dynamics
He ML Steering Wheel Torque Sensor ATESTEO represents the definitive tool for evaluating steering dynamics in the range of 50 Nm to 400 Nm. Designed to be mounted in a Effective On the steering column, this measuring wheel uses Distortion Gauge (DMS) technology to provide mechanical stability Superior in trials of Electric Mobility and conventional vehicles.
Essential Applications in e-Mobility and Automotive
This multiaxial transducer is Essential For analyzing steering force, steering wheel return, and evaluating the electric power steering (EPS) system. Thanks to its integrated high-resolution angle measurement (0.05°), it guarantees complete and accurate data capture in handling tests, providing maximum Security in the validation of the most demanding driver assistance systems.
Advantages: Angle Measurement and Zero Maintenance
The main advantage of ML Flyer Its strength lies in its ability to measure torque and angle simultaneously with precision Superior of 0.10%. Its contactless telemetry system eliminates physical wear and ensures smooth operation Effective No need for preventative maintenance. Integration with the unit VETAS3 It allows managing CAN 2.0B and analog outputs with complete Security and transparency.
Frequently Asked Questions (FAQ)
What angular resolution does the ML measuring wheel offer?
The model ML offers angle resolution Superior of 0.050°, which allows capturing even the slightest movement during complex vehicle dynamics tests, ensuring that validation in the Mobility sea 100% precise.
Is the ATESTEO ML sensor compatible with different types of steering wheels?
Yes, the system ML It is designed to be installed with complete Security through customizable adapter kits, allowing its use in a Effective in a wide variety of steering column geometries and steering wheel diameters.
Properties
| Nominal Range (Torque) | 50 / 100 / 200 / 400 Nm |
| Accuracy Class (Torque) | 0.10 % (≤ ±0.15 % analog) |
| Measurement Principle | Strain gauges (DMS) |
| Angle Resolution | 0.050° (7,680 pulses/rev) |
| Angular Velocity Resolution | 0.10 °/s |
| Signal Outputs | Frequency (TTL), Voltage (±10V), CAN Bus 2.0B |
| Linearity and Hysteresis | ≤ ±0.03 % … ±0.10 % |
| Sensitivity (Analog) | 5.0 / 10.0 / 2.5 / 5.0 V |
| Feeding | 12 V DC (Range 9…36 V) |
| Current Consumption | < 0.70 A (Measurement) / < 2 A (Starting) |
| Temperature Range (System) | -10°C … +70°C (Operational) |
| Torque Limit (Static) | Up to 325% of the Nominal Pair |
| Breaking Point | Up to 750% of the Nominal Pair |
| System Weight | approx. 1.30 kg |
| Building Material | High-strength steel |
| Compatible Control Unit | VETAS3 |
