Schreiber Messtechnik SM64

The Schreiber Messtechnik SM64 inductive angle sensor is a high-precision inductive angle sensor designed for industrial applications requiring accurate measurements in confined spaces. With a diameter of 104 mm, this sensor integrates a dual measurement system that allows measuring two angle ranges up to 60°, offering a versatile solution for various angle measurement needs.

The operating principle of the SM64 is based on differential induction. An iron-nickel alloy rotor rotates through two halves of a differential coil. The position of the rotor generates an inductance distribution proportional to the angle of rotation, allowing for precise, contactless measurement. This technology ensures high reliability and durability in demanding industrial environments.

This sensor offers a variety of output options, including current (0-20 mA or 4-20 mA) and voltage (±10 V or 0-10 V) signals, to suit the specific needs of each application. Its robust and compact construction, together with IP65 protection, make it suitable for demanding industrial environments.
