MULTICAL
Generator – simulator of PROCESS electrical signals.
- Manufacturer: DPF Sensors
- Category: Calibrators and Simulators, Signal converters, INSTRUMENTATION
Generator – simulator of PROCESS electrical signals. Generates Vcc (0 to 10 Vcc), mV (0 to 100 mV), mA (0 to 20 mA), thermocouples (J, K, R, S, T), and load cells (Wheatstone Bridge). High precision (64,000 points).
Properties
