DS5 / DS5P – Programmable electronic pressure switch
- Manufacturer: ADZ Nagano
- Category: Pressure, SENSORS
The ADZ DS5P electronic pressure switch offers a modern solution for monitoring pressure and triggering switching signals in industrial environments. Thanks to its robust stainless steel design and programmable electronics, it allows for precise adjustment of the switching point and eliminates the hysteresis typical of mechanical models.
It is available in measurement ranges from 0.2 bar to 5,000 bar, with digital (NPN/PNP) or mixed digital output, and has an internal resolution of approximately 10,000 steps. Its supply voltage ranges from 10 to 32 V DC, facilitating its integration into modern automation systems.
This model is particularly suitable for applications in hydraulics, pneumatics, industrial air conditioning, machinery automation and mobile environments, thanks to its robust construction, customization options and long-term stability.
Properties
| Parameter | Typical value / information |
|---|---|
| Measuring range | Vacuum up to 5,000 bar (depending on the version) |
| Total accuracy | Ex. ≤ ± 0.5 % FS (≤ 2 000 bar) / ≤ ± 1.0 % FS (> 2 000 bar) |
| Serving temperature | -40 °C to +125 °C in many versions |
| Electrical outlet | Switching: NO / NC / configurable window; typical switching current up to 1 A DC |
| Power supply | 10…30 V DC (approximately) |
| Connectivity / Parameterization | Programming via PC software; multiple adjustable parameters (hysteresis, delay, window mode, logic inversion) |
| Protection / Construction | Stainless steel construction; ATEX/Ex version available; IP protection depending on version |
| Typical applications | Industrial vehicles, construction machinery, hydraulics, industrial processes, maritime, automotive, etc. |
